Sany Crane 100 Ton With High Performance For Sale
The SANY Crane 100 ton, specifically the SCC1000A model, is a robust crawler crane designed for a variety of heavy lifting tasks. Here is a detailed description of Sany crane 100 ton features:
General Specifications:
- Model: SCC1000A
- Maximum Lifting Capacity: 100 tons
- Boom Length: Extendable from 13 meters to a maximum of 64 meters
- Engine: Isuzu 6HK1, delivering a rated output of 212 kW at 2,000 rpm
Performance Features:
- Lifting Moment: Maximum lifting moment of 412 t·m
- Boom Luffing Angle: 30° to 80°
- Fixed Jib Configuration: Extendable from 9 to 18 meters, allowing a combined boom and jib length of up to 82 meters (64 + 18 meters)
Operation Speed:
- Rope Speed of Main/Auxiliary Winch: 0~135 m/min
- Rope Speed of Boom Hoist Winch: 0~70 m/min
- Slewing Speed: 2.5 rpm
- Travel Speed: 0~1.6 km/h
Safety and Reliability:
- Load Moment Limiter: Provides comprehensive protection to lifting operations with accuracy up to ±3% through online non-load calibration
- Hydraulic System: Equipped with components like balance valve, overflow valve, and two-way hydraulic lock for stable and reliable operation
Transportation and Mobility:
- Transport Weight with Basic Boom: 91 tons
- Rear Counterweight: 31.2 tons
- Carbody Counterweight: 5.5 tons
- Machine Transport Dimension (with Crawler Frames and Boom Base): 13,300 x 3,490 x 3,450 mm
- Gradeability: 30%, allowing effective operation on slopes and uneven terrain
Wire Rope Specifications:
- Main Hoist Wire Rope: Diameter 26 mm, Length 240 meters
- Auxiliary Hoist Wire Rope: Diameter 26 mm, Length 180 meters
- Rated Single Line Pull of Main/Auxiliary Hoist Wire Rope: 12 tons
The SANY SCC1000A crawler crane is designed to combine strength, reach, and efficient operation, making it ideal for large-scale construction projects, infrastructure work, and other industrial lifting applications. Its versatility and powerful engine ensure reliable performance in a wide range of challenging environments.
Specification for the Sany Crane 100 ton:
| Specification Category | Details |
|---|---|
| Model | SCC1000A-Sany Crane 100 ton |
| Type | Crawler Crane |
| Maximum Lifting Capacity | 100 tons |
| Boom Length | Extendable from 13 meters to a maximum of 64 meters |
| Engine | Isuzu 6HK1, rated output of 212 kW at 2,000 rpm |
| Lifting Moment | Maximum lifting moment of 412 t·m |
| Boom Luffing Angle | 30° to 80° |
| Fixed Jib Configuration | Extendable from 9 to 18 meters, combined boom and jib length up to 82 meters (64 + 18 meters) |
| Operation Speed | |
| Rope Speed of Main/Auxiliary Winch | 0~135 m/min |
| Rope Speed of Boom Hoist Winch | 0~70 m/min |
| Slewing Speed | 2.5 rpm |
| Travel Speed | 0~1.6 km/h |
| Safety and Reliability | |
| Load Moment Limiter | Comprehensive protection with accuracy up to ±3% through online non-load calibration |
| Hydraulic System | Equipped with balance valve, overflow valve, and two-way hydraulic lock for stable operation |
| Transportation and Mobility | |
| Transport Weight with Basic Boom | 91 tons |
| Rear Counterweight | 31.2 tons |
| Carbody Counterweight | 5.5 tons |
| Machine Transport Dimension (with Crawler Frames and Boom Base) | 13,300 x 3,490 x 3,450 mm |
| Gradeability | 30% |
| Wire Rope Specifications | |
| Main Hoist Wire Rope | Diameter 26 mm, Length 240 meters |
| Auxiliary Hoist Wire Rope | Diameter 26 mm, Length 180 meters |
| Rated Single Line Pull of Main/Auxiliary Hoist Wire Rope | 12 tons |
